AirOxi Tube Blue line High Efficiency tube

Regular price Rs. 139.00
Sale price Rs. 139.00 Regular price Rs. 200.00
Unit price
Compare Ask a question

Ask a Question

* Required fields

 Size guide Share

  • Estimated Delivery:Jun 10 - Jun 14

AirOxi Tube Blue line High Efficiency tube - 3

AirOxi Tube Blue line High Efficiency tube

Regular price Rs. 139.00
Sale price Rs. 139.00 Regular price Rs. 200.00
Unit price
Product description
Shipping & Return


  • Price / Meter
  • Blue Line
  • High Efficiency Tube
  • Suitable for Root Blowers
  • 12.5 x 25 mm - AR-10

AirOxi Tube Blue line High Efficiency tube

  • Material: Elastomeric blended compound of various polymers and additives.
  • Regulatory Compliance: RoHS compliant material (RoHS Directive 2001/95/EC Amendment 2011/65/EU). Test Report available on request
  • Tube properties
(Approximate values and range given here, since actual values will differ widely)
Inside Diameter 12.5 mm (tolerance +/- 0.5 mm)
Outside Diameter 25.0 mm (tolerance +/- 0.5 mm)
Wall Thickness 6.25 mm (tolerance (+/- 0.25 mm)
Micro Hole size 0.5 to 2.0 mm
Micro Hole Density 1300 to 1800 per meter
Designed Air Flow 1.8 to 2.4 m3 / hour
Bubble Diameter 1 to 2 mm depending on water depth, air pressure, water salinity, etc.
Effective working area – 3 to 8 m2 per mtr (will vary depending on stocking density and type of culture in which it is used)
Oxygen utilization rate (%) 10 to 20%
Oxygenation capacity 0.1 to 0.2 Kg of O2 per mtr per hr depending on use
Burst Pressure 50 PSI
Effective water depth 0 to 3 mtr
Recommended blower size to tube ratio 20 to 30 mtr. per HP of blower (30 to 40 mtr. per KW of blower) depending on water depth and air flow pressure
Operating temperature range 0o Celsius to 50o Celsius \n \n

 Air Flow – Depends on blower size and output. At 2 PSI pressure and 1 mtr water head, the average flow rate per mtr is approximately 30 LPM (1.8 m3 / hr). However, since bursting is not a concern, the air flow can increase as high as required by increasing the blower and motor size. This is not however, not useful for aeration purposes since the flow will be too high to have any meaningful dissolution of air. Bubble size – varies with depth of installation and blower pressure. At 1.5 mtr depth, bubble size at exit of tube is less than 1 mm, at a pressure of 2.0 PSI. However it will change depending on salinity, air flow from blower, pressure, water depth, etc.
Usage instructions for better results
  • For best results, ensure all piping and joints are free of air leakage
  • Install at a height of at least 12” above floor of the pond. If it is PE lined pond then the tube can be installed at 6” above bottom.
  • Install on all sides of the pond
  • Operate as long as possible, preferably 24 / 7 to avoid any choking of the micro holes
  • Minimum bending radius – 0.3 mtr
  • Fittings to be used are ½” / 16 mm fittings
  • Minimum Inlet pipe size – ½’ / 12 mm
